Leica Geosystems Rugby 640 Self Levelling Manual Slope Rotary Laser Multiple Options
Tap Tap to Zoom
Product Discontinued by Manufacturer
Leica Geosystems Rugby 640 Self Levelling Manual Slope Rotary Laser has been discontinued by Leica Geosystems and is no longer available. Our product experts have helped us select these available replacements below.You can also explore other items in the Industrial / Professional Rangefinders, Professional, Surveying Equipment, Surveying Equipment yourself to try and find the perfect replacement for you!
Product Info for Leica Geosystems Rugby 640 Self Levelling Manual Slope Rotary Laser
Inside or out, the Leica Geosystems Rugby 640 Rotary Surveying Laser is versatile in levelling, aligning and squaring applications. This Leica Geosystems Rugby 640 Self-Levelling Manual Slope Rotary Laser features the Scan 90 that make layout easier by quickly moving the beam to the left or right side and an automatic and accurate plum down direction for alignment over a reference point. Save on battery by placing Leica Geosystems Rugby 640 Self Levelling Manual Slope Rotary Lasers into sleep mode without disturbing your set up.
Specifications for Leica Geosystems Rugby 640 Rotating Surveying Lasers:
| Dimensions: | 212 x 239 x 192 mm |
| Weight: | 2.56 kg / 5.6 lbs |
| Functionality: | Self-levelling horizontal, vertical, 90° and manual slope in dual axis |
| Laser class: | Class 2 |
| Laser type: | 635 nm (visible) |
| Measured at 20°C (horizontal / vertical): | ± 1.5 mm at 30 m (1/16" at 100 ft) |
| Rotation - RPS: | 0, 2, 5, 10 |
| Scanning - degrees: | 10, 45, 90 |
| Range (diameter) - Basic: | 500 m (1.650 ft) |
| Range (diameter) - RE140/160: | 600 m (2.000 ft) |
| RF remote control (diameter): | 200 m (650 ft) |
| Li-Ion battery / hours operation: | 40+ |
| Alkaline battery / hours operation: | 60+ |
| Working temperature range: | -20 to +50 °C (-4 to +122 °F) |
| Storage temperature range: | -40 to +70 °C (-40 to +158 °F) |
| Seal (both excluding and including battery pack): | IP67 |
| Warranty: | 3 years no cost |
Features of Leica Geosystems Rugby 640 Rotary Self-levelling Manual Slope Surveying Laser:
- Fit for any interior and exterior levelling, aligning and squaring application
- Scan 90 - make layout easier by quickly moving the beam to the left or right side
- Plumb Down - automatic and accurate plum down direction for alignment over a reference point
- Sleep Mode - save battery and put the Leica Rugby into sleep mode without disturbing your set up
Package Contents:
- Leica Geosystems Rugby 640 Rotary Laser Self Levelling Manual Slope
