Unfortunately Morovison Pinnacle Gen3 Night Vision Weapon Sight MVP-BNS-P is not listed by RangeFinders.
The Morovison Pinnacle Gen3 Night Vision Weapon Sight MVP-BNS-P is a unique night vision system that is small enough to mount in front of any boresighted daytime . Rifle Scope magnification can range from one to twelve power. The BNS P Generation 3 Weapon Sight from Morovision does not require any boresighting and once mounted the daysight provides the aiming point. The Morovision BNS NV Sight maintains boresight despite normal misalignments due to mount position errors and does not alter the sighting centerline (parallax is unchanged from dayscope). The BNS P+ PINNACLE also contains no beam splitter or folded optics to go out of alignment.
The MVP-BNS P+ PINNACLE Sight is a revolutionary Morovision Night Vision device when used with a high magnification fixed or variable power daytime Rifle Scope. The magnification is provided by the dayscope, which typically has much smaller optics than those associated with normal 4X or 6X night vision weaponsights. This means there is no loss in system gain or typical f/number loss associated with large hunting optics. Variable magnification dayscopes can actually zoom in (up to 12X) and still retain the same gain (image brightness) with only a slight loss in resolution. This requires 2 for use
Specifications for Morovison Pinnacle Gen3 Night Vision Weapon Sight MVP-BNS-P:
Generation:Â | Â 3 (U.S. ITT PINNACLE) | |
Resolution:Â | Â 64 lp/mm (Min) | |
Film:Â | Â Thin-Film | |
Gate:Â | Â Auto-Gated | |
Magnification:Â | Â 1x | |
Field of View:Â | Â 13 Degrees | |
Objective Lens:Â | Â 68 mm f/1.12 | |
Range of Focus:Â | Â 10mm to infinity | |
Boresight Accuracy:Â | Â within 1 MOA | |
Boresight Repeatability:Â | Â within 0.5 MOA | |
Boresight Retention:Â | Â Permanent | |
Boresight Adjustment:Â | Â None Required | |
Reticle Adj. Step Size:Â | Â 0.2 mil | |
Battery Type:Â | Â Two (2) AA batteries | |
Battery Life:Â | Â 40 hours at 70ËšF | |
Weight:Â | Â 1.9 lbs | |
Length:Â | Â 7.08" | |
Width:Â | Â 3.0in in Outside Diameter | |
Height:Â | Â 2.95" Max Above Rail | |
Package Contents:
