Leica Geosystems Rugby 280DG Laser with Remote Control, Rod Eye and NiMh Battery Pack Multiple Options
Tap Tap to Zoom
Product Discontinued by Manufacturer
Leica Geosystems Rugby 280DG Laser with Remote Control, Rod Eye and NiMh Battery Pack has been discontinued by Leica Geosystems and is no longer available. Our product experts have helped us select these available replacements below.You can also explore other items in the Industrial / Professional Rangefinders, Professional, Surveying Equipment, Surveying Equipment yourself to try and find the perfect replacement for you!
Product Info for Leica Geosystems Rugby 280DG Laser with Remote Control, Rod Eye and NiMh Battery Pack
Leica Geosystems Rugby 280 DG Construction Laser with Remote Control, Rod-Eye and NiMh Battery Pack is a horizontal, vertical and dual grade laser for any exterior or interior application. The Leica Geosystems Rugby 280DG is a multipurpose laser "Plus" with fully automatic, dual grade capability. It has a bright red beam, plumb beam, scan mode, horizontal and vertical selfleveling, plus dual grade up to 15% in both axes. Available with a two-way remote control, this Leica Geosystems laser fits well in any construction plan. This Leica Geosystems instrument is a highly accurate, general construction laser with single grade capability. The Surveying Equipment by Leica Geosystems has great accuracy, LCD grade readout and semi-automatic grade with bump alert. Whether you have to precisely lay out a construction site, perform control measurements, collect height and angle data, align concrete forms, install ceilings and partitions, lay gravity flow pipe, locate underground services or complete site preparation and earthworks - Leica Geosystems offers the right instrument, construction laser or machine control installation specifically designed for your construction application. Easy-to-use, jobsite-tough, accurate and reliable - Leica Geosystems instruments and lasers ensure the efficient use of your materials and resources. High-quality products, such as optical and electronic levels, construction lasers, total stations and machine automation systems, provide fast results, keep you working and increase your profitability.
Leica Rod Eye Plus Laser Detector Sensors with bracket is a full featured receiver with proven performance in the field. This Surveying Equipment Accessory by Leica Geosystems has three bright LED's, nine channel arrow display and audio output that provide the user with all the information needed to lock on the laser beam and get the job done right.
Additionally, Leica Geosystems surveying equipment accessory features the double beep beam finder, last beam strike memory, laser low battery indication and the reversible clamp for rectangular or oval rods. All these features put the Leica Rod Eye Plus at the top of the list for today's contractor.
- Available Models of Leica Geosystems Rugby 280 DG General Construction Laser Packages:
- 6003551: Leica Geosystems Rugby 280 DG Laser with Remote Control, Rod Eye Plus and NiMh Battery Pack
- 6003553: Leica Geosystems Rugby Laser 280DG with Remote Control, Rod Eye Digital and NiMh Battery Pack
Specifications for Leica Geosystems Rugby 280DG Laser with Rod-Eye:
| Operating Radius: | 350 m (1,150 ft) |
| Grade Capability: | Single axis +- 15% |
| Rotating Speeds: | 0, 2, 5, 10 |
| Scanning Modes: | 10, 45, 90 |
| RF Remote Control: | 100 m (330 ft) |
| Self-Leveling Accuracy: | 1.5mm per 30 m (1/16" per 100ft.) |
| Grade Accuracy: | 3.0 mm per 30 m (1/8" per 100 ft.) |
| Self-Leveling Radius: | ± 5° |
| Laser Diode: | 635 nm |
| Size (H x W x D): | 197 x 248 x 175 mm (7.8 x 9.8 x 6.9 in) |
| Weight: | 2.95 kg (6.5 lb) with batteries |
| Operating Temperature: | -20 °C to +50 °C (-4 °F to +122 °F) |
| Battery type: | Alkaline or rechargeable NiMH |
| Battery Life: | 70 hours alkaline, 40 hours rechargeable |
| Environmental: | IP67 |
| Warranty: | Two year with knockdown warranty / additional three years on request |
Package Contents:
- Leica Geosystems 280DG Rugby Laser Package with Rod-Eye and NiMhBatteries
- Leica Geosystems 768539 Rugby 280 DG, Laser with Carrying Case and Laydown Bracket
- 768543 Remote control for Rugby 280DG only
- Leica Geosystems Rod-Eye Plus with bracket 769810 (only 6003551)
- Leica Geosystem 769809 Rod-Eye Digital with bracket (only 6003553)
- 726746 NiMH Battery Pack for Rugby
- 727165 NiMH Battery Charger for Rugby, 110V
- 768840 User Manual Rugby 260-280 English, French, Spanish
